Plant Science Today (PST)

Research Articles

Vol. 12 No. sp1 (2025): Recent Advances in Agriculture by Young Minds - II

Study of whole body and hand-arm vibration in a small tractor with implements

DOI
https://doi.org/10.14719/pst.7342
Submitted
21 January 2025
Published
06-10-2025

Abstract

Mechanization is the main solution to increase work output and also to improve the timeliness of operations. In this regard, tractors are the major prime movers in Indian farms. The sale of tractors in the country was 894112 units in 2023, with exports of 97745 units. The vibration studies have been conducted for tractors of higher horsepower and power tillers, which showed that continuous operation may result in health problems to the operator. Labour shortage has triggered the use of machinery and a safe and comfortable workstation is necessary to improve and increase productivity. Hence, the study on the vibration level of small tractors will aid in reducing the risk of health hazards and in designing safety measures for the tractor operator. The whole body and hand harm vibration studies were conducted at selected speed levels using cultivator and rotavator with 20.13 kW Force tractor and 17.89 kW Kubota tractor. Instruments used to measure whole body and hand-arm vibration were B & K portable four-channel PULSE Multi-analyser 3560 C, Biometrics Data LOG (MWX8) and Accelerometer S2A-16G-MF. The whole body vibration was exceeding the exposure action value of 0.5 ms-2 and Exposure Limit Value of 1.15 ms-2 while operating the cultivator, but within the limits when operating the rotavator. The hand-arm vibration was within the Exposure Action Value of 2.5 ms-2 and Exposure Limit Value of 5 ms-2 for the force tractor. Similar results were obtained for the Kubota tractor; however, the vibration was less than that of the force tractor.

References

  1. 1. Ismail S. Farm mechanization in India–pull needs. Agric Eng Today. 2023;47(2):40–3. https://doi.org/10.52151/aet2023472.1643
  2. 2. Mehta CR, Bangale RA, Chandel NS, Kumar M. Farm mechanization in India: status and way forward. Agric Mech Asia Africa Latin Am. 2023;54(2):75–88.
  3. 3. Singh A, Samuel S, Singh H, Kumar Y, Prakash C. Evaluation and analysis of whole-body vibration exposure during soil tillage operation. Safety. 2021;7(3):61.https://doi.org/10.3390/safety7030061
  4. 4. Singh A, Samuel S, Dhabi YK, Singh H. Whole-body vibration: characterization of seat-to-head transmissibility for agricultural tractor drivers during loader operation. Smart Agric Technol. 2023;4:100164. https://doi.org/10.1016/j.atech.2022.100164
  5. 5. Singh A, Singh LP, Singh S, Singh H, Prakash C. Investigation of occupational whole-body vibration exposure among Indian tractor drivers. Int J Hum Factors Ergon. 2018;5(2):151–65. https://doi.org/10.1504/IJHFE.2018.092240
  6. 6. Bhiwapurkar MK, Saran VH, Harsha SP. Effects of vibration magnitude and posture on seat-to-head-transmissibility responses of seated occupants exposed to lateral vibration. Int J Veh Noise Vib. 2016;12(1):42–59. https://doi.org/10.1504/IJVNV.2016.077472
  7. 7. Almeida SV, Sperotto FC, da Silva Doimo L, da Silva Correia TP, Silva PR. Analysis of vibration levels in an agricultural tractor with and without a cabin. Afr J Agric Res. 2015;10(53):4945–9. https://doi.org/10.5897/AJAR2015.10421
  8. 8. Gialamas T, Gravalos I, Kateris D, Xyradakis P, Dimitriadis C. Vibration analysis on driver’s seat of agricultural tractors during tillage tests. Span J Agric Res. 2016;14(4):e0508. https://doi.org/10.5424/sjar/2016144-9664
  9. 9. Adam SA, Jalil NA. Vertical suspension seat transmissibility and SEAT values for a seated person exposed to whole-body vibration in agricultural tractor preliminary study. Procedia Eng. 2017;170:435–42. https://doi.org/10.1016/j.proeng.2017.03.070
  10. 10. International Organization for Standardization (ISO). Mechanical vibration and shock—evaluation of human exposure to whole body vibrations Geneva: ISO; standard 2631–1. Available from: https://www.iso.org/standard/50905.html
  11. 11. Taghizadeh-Alisaraei A. Analysis of annoying shocks transferred from tractor seat using vibration signals and statistical methods. Comput Electron Agric. 2017;141:160–70. https://doi.org/10.1016/j.compag.2017.07.020
  12. 12. British Standards Institution (BSI). Guide to measurement and evaluation of human exposure to whole-body mechanical vibration and repeated shock. London: BSI; 1987. BSI standard 6841:1987. https://doi.org/10.3403/00171912
  13. 13. Singh A, Samuel S, Singh H, Singh J, Prakash C, Dhabi YK. Whole body vibration exposure among the tractor operators during soil tillage operation: an evaluation using ISO 2631-5 standard. Shock Vib. 2022;2022:6412120. https://doi.org/10.1155/2022/6412120
  14. 14. Fu H, Chen Y, Yu Y, Jin M. Research on hand-transmitted vibration prediction model of the handheld EVA power tool. Appl Sci. 2022;12(20):10373. https://doi.org/10.3390/app122010373
  15. 15. Chaturvedi V, Kumar A, Singh JK. Power tiller: vibration magnitudes and intervention development for vibration reduction. Appl Ergon. 2012;43(5):891–901. https://doi.org/10.1016/j.apergo.2011.12.012
  16. 16. International Organization for Standardization (ISO). Mechanical vibration—measurement and evaluation of human exposure to hand-transmitted vibration—part 1: general requirements. Geneva: 2001. ISO 5349–1:2001.
  17. 17. Zhao X, Schindler C. Evaluation of whole-body vibration exposure experienced by operators of a compact wheel loader according to ISO 2631-1:1997 and ISO 2631–5:2004. Int J Ind Ergon. 2014;44(6):840–50. https://doi.org/10.1016/j.ergon.2014.09.006
